Zero Holder Filter

Zero Holder Filter
Zero Holder Filter
Product Code : ZE
Product Description

Our organization is counted among the most trusted manufacturers, traders, exporters and suppliers of Heavy Duty Damper Valve to our valuable clients from Maharashtra, India. Offered valves are utilized for controlling or regulating the flow of liquid, gas and many other materials. We utilized advance technology and finest quality material in manufacturing process of our products.  Further, our quality controllers stringently tested this heavy duty damper valve for its performance and quality on diverse stages of quality parameters.

DESCRIPTION :- "ZABS" Zero Hold-Up Horizontal Plate closed pressure filter that meets all the demands for a filtration which would discharge solid free filtrate. Design of Filter Press is according to cGMP & FDA approval.

Salient Features :-

  • All contact parts are in AISI SS 304 / SS 31 / AISI SS 316L.
  • Components are Argon Arc welded & polished to Mirror finish.
  • SS Jacket can be provided for hot filtration. (Optional) Provides crystal clear filtration by filtering particles upto 1 Micron Size.
  • No Scavenger arrangement is required.
  • No liquid between the Tank & the Cartridge.
  • Top dome structure ensures fast & easy removal of cartridge assembly & cleaning of cake.
  • Uniform filter aids & cake distribution.
  • SS Pump mounted on SS Trolley with 'ZABS' make heavy duty thrust ball bearing castor wheels for easy movement.
  • Provided with different types of pumps depending on the viscosity of liquid & output i.e. Centrifugal Pump, Gear Pump, Lobe Pump, Roto Pump etc..
  • Provided with Bypass System, Safety Valve & Simple Collecting device.
  • No contamination of internal surface of the shell.
  • Horizontal Plate Zero Hold-Up Filter Press is constructed in such manner that it prevents evaporation, oxidation, leakage & fumes escaping from product.
  • Plates are available in two sizes - Deep Plate for higher percentage of caking holding capacity & Shallow Plate for lesser percentage of cake holding capacity.
  • Filter Plate & thickness of cake prevents the cake dropping as well as cracking, thus assuring better filtrate quality.
  • According to requirement filtration area & cake holding capacity can be increase or decreased.

Technical Specification :

Model

Type

Plates DIA (Inch)

Filter Plates

Filter Area (M2)

Cake Holding Capacity (Ltrs)

Output (Ltrs/Hr)

Pump

Dimensions

ZE-86

Shallow

8"

6

0.212

4.8

600

1/2"

850 x 550 x 900

ZE-88

Shallow

8"

8

0.282

6.4

700

1/2"

850 x 550 x 950

ZE-148

Shallow

14"

8

0.750

25

1800

1"

1000 x 750 x 1200

ZE-1410

Shallow

14"

10

0.938

30

2000

1"

1000 x 750 x 1250

ZE-188

Deep

18"

8

1.270

53

3500

1 1/2"

1200 x 750 x 1250

ZE-1812

Deep

18"

12

1.905

80

4000

1 1/2"

1200 x 750 x 1450

ZE-1815

Shallow

18"

15

2.276

44

5000

1 1/2"

1200 x 750 x 1450

ZE-1823

Shallow

18"

23

3.489

68

7000

1 1/2"

1200 x 750 x 1650

ZE-2412

Deep

24"

12

3.450

149

7000

2"

1100 x 1550 x 1350

ZE-2415

Shallow

24"

16

4.407

84

8000

2"

1100 x 1550 x 1550

ZE-2424

Shallow

24"

24

6.611

125

12500

2"

1100 x 1550 x 1850

ZE-337

Deep

33"

7

4.020

176

8200

2 1/2"

1325 x 1325 x 1700

ZE-3310

Shallow

33"

10

5.364

151

11500

2 1/2"

1325 x 1325 x 1775

ZE-3314

Shallow

33"

14

7.510

211

15500

2 1/2"

1325 x 1325 x 1975
